GasGas MC 250F 2023
It’s our ‘little’ 4-stroke that’s big on fun and guaranteed to put a
massive smile on your face! Competition-ready, the GasGas MC 250F caters to a
huge range of riders so whether you’re just starting out and hitting the
local tracks, or chasing after championships titles, this bike is for
you! With a compact motor creating peak power at 14,000rpm it goes
without saying that this thing absolutely rips.
Sleek red bodywork allows for unrestricted movement on the GasGas MC 250F for
total control when you’re getting on the gas or hitting the brakes hard.
Complete with a high grip, and all-red seat cover, you’ll take to the track
in complete control.
Less time working on bikes means more time riding bikes, which is exactly why you’ll love the straightforward, no-tools-needed filter mounting system on all GASGAS motocross bikes. Allowing quick and easy filter changes, the airbox is designed with precisely positioned inlet ducts that ensure maximum airflow and protection of the Twin Air filter.
HANDLEBAR, GRIPS AND THROTTLE ASSEMBLY
Hold on, it’s important! We fit all GASGAS motocross bikes with quality Neken tapered handlebars, guaranteeing comfort and control thanks to optimal pressure points on the rider’s hands. The left-side ODI grip doesn’t require gluing, while on the right, the vulcanized grip features an innovative integrated throttle mechanism. With easy-to-adjust free-play, by changing a cam, the progression of the throttle can also be altered.
We like to keep our fuel tanks simple and robust, that’s why we opted for a threaded filler cap that provides a tight and reliable seal and positioned the external fuel line to make sure it’s less exposed and susceptible to damage. The black 7-litre lightweight polythene fuel tanks feature direct internal line routing from the pump to the flange, for optimal fuel flow.
The technology in our frames ensures riders enjoy playful handling and an energetic feeling on any motocross tracks. Underneath the red powder coating there’s a lightweight chromium molybdenum steel, hydro-formed, laser-cut, and robot-welded chassis that’s built to perform. Designed to be rigid where it needs to be rigid and to flex where flex is needed, it provides exceptional rider feedback, energy absorption and straight-line stability.
With a short and compact profile all GASGAS motocross subframes are made from lightweight aluminum. The profile helps centralize mass while also keeping weight down.
FORGED TRIPLE CLAMPS
Featuring a 3-way handlebar adjustment that allows riders to set up the front end of their bikes just the way they like it, the forged, 22mm offset triple clamps work in harmony with our WP front forks to help deliver precise handling and stability.
All GASGAS motocross models are equipped with advanced, super-lightweight 48mm WP XACT upside-down forks that are easily adjustable. Delivering progressive and consistent damping no matter how rough the track, they feature a capsulated air spring and pressurized oil chamber together with another internal damping wizardry. The end result is outstanding rider comfort and front-end confidence.
Traction is what it’s all about and our fully adjustable WP XACT rear shock provides the advanced damping that inspires confidence and ignites fun. Designed to work harmoniously with both frame and swingarm to offer incredible energy absorption, the shock is also matched to a linkage system with a specific geometry that further aids traction. Rebound and high/low-speed compression adjustment and 300mm of travel mean GASGAS motocross bikes are ready to take on the roughest tracks.
Light, strong, and featuring visible chain adjustment marks to make life at the track easier, our motocross swingarms are made using a gravity die-cast process to guarantee durability and precision.
The performance our compact 250cc motor kicks out is nothing short of incredible. That’s all thanks to clever manufacturing that allows 46hp to be squeezed from the 25.9kg power unit when revved at 14,000 rpm. As well as its awesome power, the compact design also improves the overall handling of the bike.
CYLINDER HEAD AND BALANCER SHAFT
The GasGas MC 250F loves to be revved, which is all possible thanks to the DOHC cylinder head that features large titanium valves and finger followers with a tough Diamond Like Carbon (DLC). The result is minimal friction and optimal performance. The carefully designed combustion chamber produces efficient, high-level power across the entire rev range with the motor also fitted with a multifunctional balancer shaft, which drives the coolant pump and the timing chain.
CYLINDER AND PISTON
Performing an important role in delivering the lively performance that makes the GasGas MC 250F so much fun to ride, both the cylinder and piston are professionally engineered from high-strength aluminum. Guaranteeing outstanding performance and reliability the 78mm bore houses a rigid, forged bridged-box-type piston made by CP.
The right gear, every time. With a low-friction coating on the internal shifting fork, all 5 gear changes on the GasGas MC 250F are smooth and purposeful. Light and durable, and featuring motocross-specific ratios, the 5-speed transmission itself ensures all power is transferred to the rear wheel, exactly when it’s needed.
Up and down, round and round… life’s tough being a 250F crankshaft. Good job that the spinning heart of the GasGas MC 250F motor is designed to offer durability and the best possible performance. Carefully located within the motor it also helps centralize oscillating masses for super easy handling.
The protective housing that keeps all internal components safe and secure! Holding all internal parts in the perfect positions to achieve the ideal center of gravity, the high-pressure casting process ensures strength and thin wall thickness for minimal weight.
Our exhaust systems are key to the power delivery of all GASGAS motocross bikes. Developed to be slim using an innovative 3D process, they comply with FIM sound regulations, look great and most importantly deliver the very best performance. The GasGas MC 250F features two-part exhaust systems that are expertly designed to deliver awesome performance at the lowest possible weight. They can also be removed without needing to take out the rear shock! Further innovation allows for a short, compact silencer that keeps sound levels down and looks up.
The GasGas MC 250F features a Diaphragm Steel (DS) clutch, which is robust, super reliable, and contributes to the compact design of the engine. Featuring a single diaphragm steel pressure plate instead of traditional coil springs, it also has a clutch basket CNC machined from a single piece of steel for incredible durability.
Fast is fun but slowing down is essential, which is why all GASGAS
motocross bikes are fitted with Brembo calipers and controls. With 260mm
front and 220mm rear disks, braking is easy, inspiring riders to push
harder and ride faster.
BREMBO HYDRAULIC CLUTCH
No need for adjustment and a near maintenance-free operation, but the best thing about the Brembo hydraulic clutch is that it delivers a perfectly smooth action time and time again. With lever free-play automatically adjusted, the biting point and function of the clutch remain constant no matter if it’s hot or cold.
INTEGRATED COOLING SYSTEM AND RADIATORS
Keeping our bikes slim means better handling, which is why the GASGAS motocross range features cooling systems that are integrated into the frames. Also allowing for improved cooling due to eliminating the need for additional hoses, together with the high-strength, lightweight radiators the complete system ensures, well, our bike stays super cool no matter how tough the conditions!
Built to take a beating, our wheels are ready to play rough. No matter how heavy the landing or how rough the track is, the silver, high-strength rims, CNC machined hubs, and lightweight spokes deliver maximum strength for complete peace of mind.
Connecting rider and bike to the track the Maxxis MaxxCross MX-ST tires are designed to be durable, grippy, and deliver the performance that completes our proven performance bikes. Inspiring confidence and boosting predictability, the tread pattern is designed to maximize both traction and braking performance.
ENGINE MANAGEMENT SYSTEM
Super small but the best there is when it comes to processing engine
data. Used to control all parameters linked to the fuel-injection system, the Keihin EMS unit also features a gear sensor that allows a
tailored power delivery for each gear.
44MM THROTTLE BODY
The GasGas MC 250F uses a 44mm Keihin throttle body with an injector positioned to ensure the most efficient flow of fuel mixture into the combustion chamber. But what’s most important to all riders is the fact that the direct cable mounting system ensures an immediate throttle response.
ELECTRIC START AND LI-ION BATTERY
No need to kick, kick, kick! All GASGAS 4-stroke motocross bikes are fitted with an electric starter as standard. Saving time at the start of a day when a motor’s cold, or near the end of a race when the motor’s hot, with the simple press of a button the GasGas MC 250F fires into life. Using a lightweight Li-Ion 2.0 Ah battery together with a robust starter motor from Mitsuba and a reliable starter drive guarantees reliable starting. Always.
